MAG 70DM IF-70 MHZ MOD/DEM 2 VIDEO 4 AUDIO
| VIDEO PERFORMANCE |
| Video in/out: | 2 x CVBS SD |
| Video in/out level: | 1 Vpp / 75R |
| Video compression: | MPEG2 MP@ML |
| Maximum resolution: | PAL 720x576@25fps |
| Quality: | Full D1 |
| |
| AUDIO PERFORMANCE |
| Capacity: | 2 x stereo unbalance (balance XLR optional) |
| Audio compression: | MPEG1 Layer II
|
| Audio in/out level: | 2 Vpp |
| |
| TRANSMITTER |
| DVB-T standard: | ETSI EN 300 744 |
| Frequency: | 70MHZ ± 200Khz |
| Output level: | 0dbm/50R |
| Carriers: | 2K, 8K |
| Modulation: | 16QAM, 64QAM |
| Guard intervals: | 1/4, 1/8, 1/16, 1/32 |
| Code rate: | 1/2, 2/3, 3/4, 5/6, 7/8 |
| Bandwidth: | 8 Mhz |
| Band noise: | 70dbc |
| MER: | 38db |
| |
| RECEIVER |
| DVB-T standard: | ETSI EN 300 744 |
| I.F. bandwidth: | 8 Mhz |
| Frequency: | 70MHZ ± 200Khz |
| Input level: | (-95) - (-35)dbm |
| |
| GENERAL |
| System capacity: | 2 Video + up to 4 audio channels |
| System Bandwidth: | 8 MHz |
| I.F. frequency: | 70 MHz |
| I.F. I/O level: | 0 dBm |
| I.F. I/O impedance: | 50R |
| I.F. I/O return loss: | > 24 dB |
| Operating temperature: | From 0°C to +45°C |
| Main supply: | 220 V AC ± 10% |
|
|
|
|
